- Shell
- Thread Diameter 12mm
- Thread Pitch 1.25mm
- Seat Type Gasket
- Reach19mm (3/4")
- Hex Size5/8" (16mm)
- Terminal Type Removable Nut
- Overall Height JIS
- Gap.031" (0.8mm)
- Center Electrode
- MaterialNickel
- TypeStandard
- Size2.5mm
- ProjectionProjected
- Ground Electrode
- MaterialNickel
- TypeStandard
- Quantity1
- Specifications
- ResistorYes
- Resistor Value5k Ohm
- Heat Range7
- Torque SpecsCast Iron: 10.8-18 lb. ft. Aluminum: 10.8-14.5 lb. ft.
