- Shell
- Thread Diameter 10mm
- Thread Pitch 1.0mm
- Seat Type Gasket
- Reach 26.5mm (1.04")
- Hex Size 9/16" (14mm)
- Terminal Type Threaded Stud
- Gap .035" (0.9mm)
- Center Electrode
- Material Iridium
- Type Fine Wire
- Size 0.6mm
- Projection Non-Projected
- Ground Electrode
- Material Platinum
- Type Standard
- Shape Taper Cut
- Quantity 1
